The most powerful and most capablemining containers in the world
The most powerful and most capable Immersion Container: 4MW of heat rejection, 64 DCX PRO Enclosures | 640-720x Whatsminer M56 or 512-576x Bitmain S19 models
Complete 40ft mobile immersion system combined with 2 x 2 MW Immersion Optimized Dry coolers and complete primary and secondary hydraulic systems with optional or integrated switchgear system


OVERVIEW
Small but dense Immersion Crypto Mining Containers as DCX patent pending containerized system with immersion liquid cooling technology is the answer for all the problems that bother industry sized cryptocurrency mining farms. DCX Immersion Mining Containers solves all issues with proprietary, patent-pending granular Immersion Enclosure fluid distribution. The unmatched density of 700 to even 800 ASIC miners installed in immersion enclosures results in 2 to 4 MW power density. Each of our Immersion Containers is equipped with its own second loop pumping and heat exchange station. DCX’s second loop fluid distribution system circulates our ThermaSafe R dielectric Heat Transfer Fluid. Single-phase liquid has 1600 x better heat capacity and 4.5x better heat conductivity than air. Our fluid transports 100% of heat outside the enclosure and protects devices from the harsh environment and failure mechanisms including high temperature, humidity, vibration, corrosion, dust – major causes of electronic failures. Reduces thermal expansion cycling, maintains a constant temperature, eliminates airborne contaminants, and failures due to zinc and tin whisker growth. ThermaSafe R works also as a fire suppressant making sure you are protected even in remote mining operations.
Based on the DCX Scale Out PRO10 Immersion Enclosures and Immersion Rack Systems, PRO10 HD container includes a complete hydraulic system. Containers are available with maximized miners density (all rack build) or with Low Power Switchgear components to be built-in within the container frame. Available in standard 20HC or 40HC ISO format, easy to transport and commissioning at any destination, PRO10 HD containers are based on standard ISO container and hold CSC certification. System can be delivered with:
- complete immersion cooling system with hydraulic loop and standard adaptations & wiring built-in, to be later integrated with switchgear option at investor site,
- turnkey solution including switchgear, power distribution and all options and accessories for region specific (UL / CE / ELTEK) certification.
System capacity:
- – 20HC: 2MW Heat Transfer Capacity 256 x S19 / 320 x M56 / 384 x M30
- – 40HC: 4MW Heat Transfer Capacity 576 x S19 / 720 x M56 / 864 x M30
System density options:
- DCX 20HC: 2MW Heat Transfer Performance – 256 x S19 / 320 x M56 / 384 x M30
- DCX 20HC-PD: 1.7 MW Heat Transfer Performance. Turnkey system with full power distribution (switchgear) and accessories included – 192 x S19 / 240 x M56 / 288 x M30
- DCX 40HC: 4MW Heat Transfer Performance – 576 x S19 / 720 x M56 / 864 x M30
- DCX 40HC-PD: 4MW Heat Transfer Performance. Turnkey system with full power distribution (switchgear) and accessories included – 512 x S19 / 640 x M56 / 768 x M30
FEATURES
-
70% higher heat transfer performance than any other solution
-
Hosts new M56 / M50 and overclocked S19 miners.
-
30-40 x M56 miners per Immersion Rack
-
4MW and 720 miners – most powerful and affordable Immersion Mining Containers
Form Factor ISO Standard | 20HC 3L | 20HC 4L | 20HC PD 3L | 20HC PD 4L | 40HC 3L | 40HC 4L | 40HC PD 3L | 40HC PD 4L | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Primary Loop Hydraulic System | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | |||||||
Dual Side Access | Included | Included | Included | Included | Included | Included | Included | Included | |||||||
Power and Ethernet Cable Tray | Included | Included | Included | Included | Included | Included | Included | Included | |||||||
Led Lighting | Included | Included | Included | Included | Included | Included | Included | Included | |||||||
Ventilation / Exhaust Fans | Included | Included | Included | Included | Included | Included | Included | Included | |||||||
Grounding & Lightning protection | Included | Included | Included | Included | Included | Included | Included | Included | |||||||
1P Internal Power Cabling | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | Built-in | |||||||
3P Miner Power Cabling | Not included | Not included | Not included | Included | Not included | Not included | Included | Included | |||||||
Main Power Switchgear | Not included | Not included | Included | Included | Not included | Not included | Included | Included | |||||||
PDUs | Not included | Not included | Included | Included | Not included | Not included | Included | Included | |||||||
Aggregation Switches & cabling | Not included | Not included | Included | Included | Not included | Not included | Included | Included | |||||||
Rack Frames | 8 | 8 | 6 | 2*3 | 18 | 18 | 14 | 16 | |||||||
Pro10 Enclosures | 24 | 32 | 18 | 24 | 54 | 72 | 42 | 64 | |||||||
Max. Enclure heat transfer (kW) | 64 | 64 | 64 | 64 | 64 | 64 | 64 | 64 | |||||||
Thermasafe R Volume (L) | 5280 | 7040 | 3960 | 5280 | 11880 | 15840 | 9240 | 14080 | |||||||
Miner Qty. S19 form factor | 192 | 256 | 144 | 192 | 432 | 576 | 336 | 512 | |||||||
Miner Qty. M56 form factor | 240 | 320 | 180 | 240 | 540 | 720 | 420 | 640 | |||||||
Miner Qty. M30 form factor | 288 | 384 | 216 | 288 | 648 | 864 | 504 | 768 | |||||||
Max. Power S19 (kW) | 8 | 8 | 8 | 8 | 8 | 7 | 8 | 8 | |||||||
Max. Power M56 (kW) | 7 | 6.4 | 7 | 7 | 7 | 5.5 | 7 | 6.25 | |||||||
Heat Transfer Capacity S19 (kW) | 1536 | 2048 | 1152 | 1536 | 3456 | 4032 | 2688 | 4096 | |||||||
Heat Transfer Capacity M56 (kW) | 1680 | 2048 | 1260 | 1680 | 3780 | 3960 | 2940 | 4000 | |||||||
Actual Heat Transfer Capacity | 1,7 MW | 2 MW | 1,2 MW | 1,7 MW | 3,8 MW | 4 MW | 3 MW | 4 MW | |||||||
Maximum Heat Transfer Capacity | 2 MW | 2 MW | 2 MW | 2 MW | 4 MW | 4 MW | 4 MW | 4 MW | |||||||
Primary Operating Power (kW) | 5.4 | 9.3 | 3.8 | 6.4 | 14.7 | 19.7 | 10.2 | 16 | |||||||
Total Operating Power (kW) | 12.62 | 18.76 | 9.34 | 13.62 | 30.32 | 40.36 | 22.46 | 34.42 | |||||||
Primary Loop Temperatures | Supply 20-40°C | Return 40-60°C | ||||||||||||||
Ambient Operation Temperature | -5°C~40°C | ||||||||||||||
Input voltage | 3P 380-440V 50/60HZ | 1P 220V or 230V 50/60H | ||||||||||||||
Certification | CE | ||||||||||||||
Primary Loop Monitoring & Control | Remote monitoring & control: Flow, Temperatures, High Availability control and automatic switchover | ||||||||||||||
Enclosure Monitoring | Remote monitoring: Individual Temperature, Power, Heat Transfer, Alarms | 2.4" OLED TFT | ||||||||||||||
PDU (if included) | Remote monitoring & control: Power, Voltage, Alarms, Reset | ||||||||||||||
Container System | Invidual temperature and humidity control, CCTV optional | ||||||||||||||
Dry Cooler System | Supply Return Temperatures, Alarms, Fan Status, Current Power |
20HC IMMERSION MINING CONTAINER
Based on the DCX Scale Out PRO10 Immersion Enclosures and Immersion Rack Systems, they include a complete hydraulic system. Containers are available with maximized miners density (all rack build) or with Low Power Switchgear components to be built-in within the container frame.
- Heat transfer capacity: 2MW Heat Transfer Capacity
- Miner capacity: 256 x S19 / 320 x M56 / 384 x M30
System density options:
- DCX 20HC: 2MW Heat Transfer Performance – 256 x S19 / 320 x M56 / 384 x M30
- DCX 20HC-PD: 1.7 MW Heat Transfer Performance. Turnkey system with full power distribution (switchgear) and accessories included – 192 x S19 / 240 x M56 / 288 x M30
Technical Specification
Form Factor ISO Standard | 20HC 3L | 20HC 4L | 20HC PD 3L | 20HC PD 4L |
---|---|---|---|---|
Primary Loop Hydraulic System | Built-in | Built-in | Built-in | Built-in |
Dual Side Access | Included | Included | Included | Included |
Power and Ethernet Cable Tray | Included | Included | Included | Included |
Led Lighting | Included | Included | Included | Included |
Ventilation / Exhaust Fans | Included | Included | Included | Included |
Grounding & Lightning protection | Included | Included | Included | Included |
1P Internal Power Cabling | Built-in | Built-in | Built-in | Built-in |
3P Miner Power Cabling | Not included | Not included | Included | Included |
Main Power Switchgear | Not included | Not included | Included | Included |
PDUs | Not included | Not included | Included | Included |
Aggregation Switches & cabling | Not included | Not included | Included | Included |
Rack Frames | 8 | 8 | 6 | 6 |
Pro10 Enclosures | 24 | 32 | 18 | 24 |
Max. Enclure heat transfer (kW) | 64 | 64 | 64 | 64 |
Thermasafe R Volume (L) | 5280 | 7040 | 3960 | 5280 |
Miner Qty. S19 form factor | 192 | 256 | 144 | 192 |
Miner Qty. M56 form factor | 240 | 320 | 180 | 240 |
Miner Qty. M30 form factor | 288 | 384 | 216 | 288 |
Max. Power S19 (kW) | 8 | 8 | 8 | 8 |
Max. Power M56 (kW) | 7 | 6,4 | 7 | 7 |
Heat Transfer Capacity S19 (kW) | 1536 | 2048 | 1152 | 1536 |
Heat Transfer Capacity M56 (kW) | 1680 | 2048 | 1260 | 1680 |
Actual Heat Transfer Capacity | 1,7 MW | 2 MW | 1,2 MW | 1,7 MW |
Maximum Heat Transfer Capacity | 2 MW | 2 MW | 2 MW | 2 MW |
Primary Operating Power (kW) | 5,4 | 9,3 | 3,8 | 6,4 |
Total Operating Power (kW) | 12,62 | 18,76 | 9,34 | 13,62 |
Primary Loop Temperatures | Supply 20-40°C | Return 40-60°C | |||
Ambient Operation Temperature | -5°C~40°C | |||
Input voltage | 3P 380-440V 50/60HZ | 1P 220V or 230V 50/60H | |||
Certification | CE | |||
Primary Loop Monitoring & Control | Remote monitoring & control: Flow, Temperatures, High Availability control and automatic switchover | |||
Enclosure Monitoring | Remote monitoring: Individual Temperature, Power, Heat Transfer, Alarms | 2.4" OLED TFT | |||
PDU (if included) | Remote monitoring & control: Power, Voltage, Alarms, Reset | |||
Container System | Invidual temperature and humidity control, CCTV optional | |||
Dry Cooler System | Supply Return Temperatures, Alarms, Fan Status, Current Power |
FEATURES
-
70% higher heat transfer performance than any other solution
-
Hosts new M56 / M50 and overclocked S19 miners.
-
30-40 x M56 miners per Immersion Rack
-
4MW and 720 miners – most powerful and affordable Immersion Mining Containers
Quick intro
Unboxing of the Immersion Enclosure package and quick intro to the system components.
What you get – bundle
Enclosure with a 40kW dry cooler. We have a new ICP40 now, but you see what you get in the bundle package.
Installation & Startup
You bought the package – now what? Quick installation guide for effective commissioning of this smart immersion cooling system.
The most powerful and most capable Immersion Container: 4MW of heat rejection, 64 DCX PRO Enclosures | 640-720x Whatsminer M56 or 512-576x Bitmain S19 models
Complete 40ft mobile immersion system combined with 2 x 2 MW Immersion Optimized Dry coolers and complete primary and secondary hydraulic systems with optional or integrated switchgear system


OVERVIEW
Small but dense Immersion Crypto Mining Containers as DCX patent pending containerized system with immersion liquid cooling technology is the answer for all the problems that bother industry sized cryptocurrency mining farms. DCX Immersion Mining Containers solves all issues with proprietary, patent-pending granular Immersion Enclosure fluid distribution. The unmatched density of 700 to even 800 ASIC miners installed in immersion enclosures results in 2 to 4 MW power density. Each of our Immersion Containers is equipped with its own second loop pumping and heat exchange station. DCX’s second loop fluid distribution system circulates our ThermaSafe R dielectric Heat Transfer Fluid. Single-phase liquid has 1600 x better heat capacity and 4.5x better heat conductivity than air. Our fluid transports 100% of heat outside the enclosure and protects devices from the harsh environment and failure mechanisms including high temperature, humidity, vibration, corrosion, dust – major causes of electronic failures. Reduces thermal expansion cycling, maintains a constant temperature, eliminates airborne contaminants, and failures due to zinc and tin whisker growth. ThermaSafe R works also as a fire suppressant making sure you are protected even in remote mining operations.
Based on the DCX Scale Out PRO10 Immersion Enclosures and Immersion Rack Systems, PRO10 HD container includes a complete hydraulic system. Containers are available with maximized miners density (all rack build) or with Low Power Switchgear components to be built-in within the container frame. Available in standard 20HC or 40HC ISO format, easy to transport and commissioning at any destination, PRO10 HD containers are based on standard ISO container and hold CSC certification. System can be delivered with:
- complete immersion cooling system with hydraulic loop and standard adaptations & wiring built-in, to be later integrated with switchgear option at investor site,
- turnkey solution including switchgear, power distribution and all options and accessories for region specific (UL / CE / ELTEK) certification.
System capacity:
- – 20HC: 2MW Heat Transfer Capacity 256 x S19 / 320 x M56 / 384 x M30
- – 40HC: 4MW Heat Transfer Capacity 576 x S19 / 720 x M56 / 864 x M30
System density options:
- DCX 20HC: 2MW Heat Transfer Performance – 256 x S19 / 320 x M56 / 384 x M30
- DCX 20HC-PD: 1.7 MW Heat Transfer Performance. Turnkey system with full power distribution (switchgear) and accessories included – 192 x S19 / 240 x M56 / 288 x M30
- DCX 40HC: 4MW Heat Transfer Performance – 576 x S19 / 720 x M56 / 864 x M30
- DCX 40HC-PD: 4MW Heat Transfer Performance. Turnkey system with full power distribution (switchgear) and accessories included – 512 x S19 / 640 x M56 / 768 x M30
FEATURES
-
70% higher heat transfer performance than any other solution
-
Hosts new M56 / M50 and overclocked S19 miners.
-
30-40 x M56 miners per Immersion Rack
-
4MW and 720 miners – most powerful and affordable Immersion Mining Containers
Get in Touch & Get the Quote
We’d love to help you in your project with our liquid cooling systems.
We need more info:
We need basic information required to size the DCX Immersion Mining system correctly:
- type and number of ASIC miners or GPUs
- expected miners power
- your plan for heat rejection – we can deliver immersion optimized
- dry cooler or connection to local water loop
- city / country of your operation – to make sure w will deliver
- expected performance in your maximum ambient temperature and to quote shipping cost.
