This unique single or dual loop immersion tank may be upgraded with dedicated pool or plate heat exchanger and connected directly to your home or pool, replacing power hungry heaters or heat pumps. DCX Bitpod 2 is equipped with industrial pump, hydraulics and monitoring sensors with colour high-res LCD, remote temperature / status control and notifications. Typical applications: pool heating, water / boiler heating, floor heating. It’s the most universal and affordable home mining system, that can heat your home and earn money at the same time.
Hosting capacity
3 MicroBt M56/66 Whatsminer
2 Bitmain S19 / 21XP IMM Immersion Antminer
2 x Canaan Avalon 14xx / 15xx miner
Heat Transfer Capacity
+20kW
Heat Rejection
Single loop (oil cooler)
Dual loop (heat exchanger for home heating / dry cooler)
Pool (pool heat exchanger)
Monitoring
High-Res color LCD, inlet & outlet temp. sensors
Remote web based temperature, performance, status control & notification
API for data exchange
Dielectric Fluid
66LFluid In / Out[°C]60 / 40
Noise
30dB(A)
General construction
All-steel internal enclosure with heat isolation covers
Power Standard
230-240V 1Ph 50/60 Hz (120V 60hz with optional transformer)
Pump system & Connections
Industrial circulation pump
Optional plate heat exchanger (1" DN25 connection)
Optional pool heat exchanger (1 1/2" | 6/4" | DN40 connection)
Dimensions
500(W)x480(D)x500(H) mm
Weight
Approx 50 kg / 100 lbs dry | 100 kg / 200 lbs filled
1
A complete solution that consists of Bitpod, ICP15 and 66L of Dielectric fluid. Everything you need to start mining crypto immediately!
Heat your house or swimming pool with dedicated heat exchangers.
The perfect entry-level solution for anyone willing to mine crypto.
Utilize up to 15kW of heat generated by your standard-clocked miners to heat up your house, swimming pool or green-house!
A complete plug’n’play solution for anybody who is looking to kickstart a small mining operation at home.
The best quality dielectric fluid on the market included in the bundle!
2
A complete solution that consists of Bitpod, ICP15 and 66L of Dielectric fluid. Everything you need to start mining crypto immediately!
Heat your house or swimming pool with dedicated heat exchangers.
The perfect entry-level solution for anyone willing to mine crypto.
Utilize up to 15kW of heat generated by your standard-clocked miners to heat up your house, swimming pool or green-house!
A complete plug’n’play solution for anybody who is looking to kickstart a small mining operation at home.
The best quality dielectric fluid on the market included in the bundle!
